Heavy-duty Universal Conveyor Roller Series 1450
IDRD-1456N8BU03
Heavy-duty Universal Conveyor Roller Series 1450
Driven and particularly non-driven conveying systems, such as transport of cardboards, containers, barrels, wheels, pallets or steel containers. Thanks to a carrying capacity of up to 5,000 N, the product can be used as universal conveyor roller for very high loads. The roller series can also be used for the implementation of gravity roller conveyors. The version with steel bearing housing is designed for use in freezer applications or applications with very high ambient temperature.
The use of precision ball bearings, Technopolymer bearing housings and seals result in very quiet running.
The tube ends are rounded, thereby allowing materials to be easily moved on from the side.
Forces acting in axial direction are removed through ball bearings and seals.
To obtain an axial fixing of bearing housing, ball bearing and seal against escaping, the bearing housing is not only pressed into the tube, but also flanged.
