Polymer Ball Transfer Unit Series 5500
IDS-64000395
Polymer Ball Transfer Unit Series 5500
The roller is used for aligning medium-heavy materials, e.g. plates, containers or cardboards with smooth bottom. Furthermore, the roller can be used for pushing, e.g. when transporting steel or wooden plates.
The use of balls allows transporting the material in every direction. Crossings and switches can also be implemented easily. In addition, particularly soft running balls are being used.
For variants with steel balls, a felt seal keeps out dust. Design with main balls made of stainless steel or polymer also show a high corrosion resistance.
Variants with polymer balls are available for transporting goods with sensitive surfaces.
The main ball rotates on support balls which turn on a ball socket. This accomplishes a good support of the material. The ball socket consists of stainless steel in all variants.
